DKBP – Bale Press

A baler compacts recyclable materials such as OCC, PET, mixed plastics, and light metals into tightly bound bales. Using hydraulic pressure and automated tying, it reduces volume, improves handling and transport efficiency, and prepares materials for downstream processing or export.

	UNIT	DKBP50	DKBP70k	DKBP70	DKBP90	DKBP120	DKBP150	DKBP170	DKBP200
PRESSURE POWER	ton	50	70	70	90	120	150	170	200
MOTOR	kW	15	22	37	45	75	55 + 55	75 + 75	90 + 90
FEEDING MOUTH	mm	1000 x 720	1050 x 1020	1400 x 1020	1600 x 1020	1800 x 1120	1800 x 1120	2000 x 1120	2000 x 1120
BALE SIZE	mm	750 x 750	1100 x 850	1100 x 850	1100 x 850	1200 x 1130	1200 x 1130	1200 x 1130	1200 x 1130
BALE SIZE	mm	–	1100 x 750	1100 x 750	1100 x 750	1100 x 1130	1100 x 1130	1100 x 1130	1100 x 1130
CAPACITY	Cardboard ( 30 kg/m³ )	1	3	7,5	9,5	12	16	18	19
CAPACITY	Mixed ( 50 kg/m³ )	2	5	10	14	18	24	26	28
CAPACITY	Paper ( 100 kg/m³ )	3,5	9	15	21	28	34	36	42
BALE WEIGHT	kg	250 – 500	400 – 700	500 – 700	600 – 950	800 – 1250	950 – 1400	950 – 1700	950 – 2000
WIRING NUMBER		3	4	4	4	5	5	5	5
OIL TANK CAPACITY	lt	600	1000	1000	2000	2500	3000	3000	3000
CONVEYOR WIDTH	mm	1000	1000	1300	1450	1600	1800	1800	2000
WIRE THICKNESS	mm	3	3	3	3	3.2	3.5 – 4	4	4
IDLE CYCLE TIME	sn	30	17	17	17	17	17	17	17
PRESS WEIGHT	ton	6	13	16	18,5	21	25	28	32

SİZE (cm)	DKBP50	DKBP70k	DKBP70	DKBP90	DKBP120	DKBP150	DKBP170	DKBP200
A	2550	3250	3600	3795	4300	4580	4580	4980
B	1000	1050	1400	1600	2000	2000	2000	2000
C	3600	3583	3600	4620	4620	4620	4620	4620
D	2155	2814	2682	2817	2850	2880	2880	2840
E	978	1328	1328	1335	1366	1420	1420	1390
F	7150	7900	8600	10000	11000	11200	11200	11600
G	4700	4700	4700	4700	5000	5000	5000	5000
H	6389	6565	6565	6570	7785	7790	7790	7775
J	2000	2000	2000	2000	2000	2000	2000	2000
K	9000	9000	9000	9000	10500	11000	11000	11000
X	6000	6000	6000	6000	6000	6000	6000	6000

Low Space Requirement

Easy Control

Easy Feeding

High Compression Ratio
